BEAM SENSOR

– Wireless Connectivity
– Active Infrared Beams
– Long-Range Detection
– Weatherproof Design
– Multiple Beam Configurations
– Low-Power / Battery Operated

– Alarm & Alerts
– Signal Reliability & Range
– Anti-Tamper Protection
– Adjustable Sensitivity & Alignment
– Integration with Security Systems
– Easy Installation & Setup

Specifications

Model CUS-BS100-VER1.0
Beams 2*2
Lamp source Infrared digital pulse
Sensor speed 50-700 msec adjustable
Outdoor alarm distance 20m-100m
Working voltage DC/AC 12V~24V
Alert output Replay contact output NO or NC
Contact Rating DC30V,0.5Amax
Temperature -25°C ~+65°C
Relative Humidity ≤95%RH,No condensation
Size 170mm*82mm*80mm
Tamper output Contact output NC
Horizontal adjust 180° (±90°)
Vertical adjust 20° (± 10°)

*Product casing and specifications are subject to change without prior notice..
